Ultra Low Cement Castable (ULCC)
Main Chemical Compositions & Categories
ULCCs are composed of the highest-purity aggregate (e.g., Tabular Alumina, White Fused Alumina, or high-grade Mullite) and an advanced, minimalist binding system. The extreme reduction in CAC binder is balanced by incorporating large amounts of highly active ultra-fine reactive powders (fumed SiO2 and/or reactive Al2O3) and high-performance dispersants to maintain fluidity and achieve maximum packing density.
| COMPONENT | CONTENT | KEY FEATURE | PRIMARY ADVANTAGE |
| Aggregate | 85% to 99% | Highest purity refractory grains | Maximum refractoriness and wear resistance |
| CAC Binder | < 1.0 CaO | Minimum Lime Content | CRITICAL: Virtually no low-melting liquid phases |
| Reactive Fines | Ultra-fine SiO2/Al2O3 | Promotes dispersion and densification | Superior final strength and low porosity |
Key Properties and Performance
| PROPERTY | TYPICAL PERFORMANCE | MECHANISM OF ADVANTAGE |
| Hot Strength/Creep | MAXIMUM | Near-zero CaO means negligible formation of detrimental glassy phases, providing brick-like performance under load. |
| Refractoriness (RUL) | HIGHEST | Maintains structural integrity up to 1800°C depending on the aggregate type. |
| Density/Porosity | MAXIMUM DENSITY | Ultra-fine particle packing and minimal mixing water achieve very low apparent porosity (AP). |
| Chemical Resistance | SUPERIOR | High purity and low porosity provide excellent resistance to penetration and chemical attack. |
Advantages and Key Characteristics
ULCC technology is used for the most severe, high-stress applications, providing a performance level comparable to ZCC (Zero-Cement Castables) but with the benefit of an initial hydraulic set.
- Near-Elimination of Creep: The primary function of ULCC. By reducing the CaO content to trace amounts, the formation of the CaO–Al2O3–SiO2 glassy phase, which is the main cause of high-temperature deformation (creep), is essentially eliminated. This allows the ULCC lining to maintain its structural dimensions under the highest thermal and physical loads.
- Maximum Purity and Stability: The low flux content makes ULCC highly resistant to chemical attack by acidic and neutral slags, as well as molten aluminum and other non-ferrous metals. The purity makes it ideal for applications sensitive to contamination.
- Superior Abrasion Resistance: The high packing density and use of the hardest aggregates (like Tabular or Fused Alumina) result in exceptional resistance to erosion and mechanical wear.
- Monolithic Reliability: ULCC allows users to replace complex, expensive high-performance brick shapes with a seamless, monolithic lining that offers comparable, and often superior, performance and longevity.
Typical Industries and Applications
ULCCs are reserved for the most critical, highest-temperature zones in industrial furnaces:
- Ferrous Industry (Steel): Critical load-bearing zones, ladle bottoms and safety linings, runners, and high-heat EAF/Ladle Furnace hot spots.
- Non-Ferrous Industry: Continuous casting funnels, high-wear launders, and refractory contact zones in primary aluminum smelting.
- Petrochemical & Chemical: Linings in severe service FCC (Fluid Catalytic Cracking) regenerators and high-temperature gasifiers.
Furnace Areas and Service Zones
They are specified for structural, high-wear, and maximum heat zones:
- HOT-FACE WORKING LINING: Used where service temperature and load are at their limits.
- TAP-HOLE AND RUNNERS: Areas exposed to high-velocity molten metal and severe thermal shock.
- STRUCTURAL SUPPORTS: Load-bearing piers and sections where dimensional stability is non-negotiable.
Key Data Sheet Properties to Consider
Selection criteria focus intensely on chemical and high-temperature mechanical properties:
- CaO Content: CRITICAL VALUE. Must be verified as < 1.0% to classify as ULCC.
- Creep in Compression (CISC): CRITICAL VALUE. Must demonstrate an extremely low creep rate at the peak service temperature (e.g., 1550°C to 1650°C).
- Cold Crushing Strength (CCS): Should be exceptionally high, often > 100 MPa, confirming maximum density.
- Mixing Water: Typically requires very low and precise water content, which is essential for maximizing density and flow (often achieved via Self-Flow technology).
Technical Guidance: ULCCs are highly specialized and sensitive materials. The mixing procedure must be exact, as the dispersants are sensitive to the mixing time and water amount. Crucially, due to their very high density and low permeability, ULCCs have the most stringent and slow dry-out and heat-up schedule of any castable. Failure to follow this schedule precisely is the leading cause of catastrophic spalling failure.
