Mullite Brick – Cast Mullite
- MAIN CHEMICAL COMPOSITIONS AND CATEGORIES
- Cast Mullite is a fusion-cast, high-purity product composed predominantly of the synthetic mineral MULLITE (3AL2O3 $\cdot$ 2SIO2).
- ALUMINA CONTENT: 70% to 75%.
- KEY FEATURE: Fusion-cast production method ensures maximum density and zero apparent porosity.
- PRIMARY ADVANTAGE: Excellent resistance to glass and molten metal penetration and corrosion.
- KEY PROPERTIES AND PERFORMANCE
- PROPERTY: POROSITY
- TYPICAL PERFORMANCE: ZERO Apparent Porosity (AP).
- VARIATION: Achieved through the fusion casting process. This is the main difference from sintered bricks.
- PROPERTY: TEMPERATURE UNDER LOAD (TUL)
- TYPICAL PERFORMANCE: EXTREMELY HIGH. Retains shape and strength near its melting point.
- VARIATION: TUL is maximized by the purity of the synthetic Mullite phase.
- PROPERTY: CORROSION RESISTANCE
- TYPICAL PERFORMANCE: OUTSTANDING against molten glass, slags, and metal penetration.
- VARIATION: Directly proportional to DENSITY and absence of interconnected pores.
- PROPERTY: THERMAL SHOCK
- TYPICAL PERFORMANCE: GOOD TO MODERATE.
- VARIATION: Density is a trade-off; the absence of pores reduces resilience to rapid temperature changes.
- PROPERTY: POROSITY
- ADVANTAGES AND KEY CHARACTERISTICS
- MAXIMUM DENSITY AND ZERO POROSITY: Eliminates pathways for molten materials (glass, metal, slag) to penetrate the brick matrix, preventing fluxing and corrosion wear. This leads to the longest campaign life in corrosive environments.
- SUPERIOR HOT STRENGTH: The interlocking crystalline structure formed during cooling of the molten material provides exceptional load-bearing capacity and creep resistance at extreme operating temperatures.
- HIGH PURITY: Made from high-purity raw materials, ensuring minimal contamination of the molten product (e.g., glass or specialty metals).
- TYPICAL INDUSTRIES AND APPLICATIONS
- GLASS INDUSTRY: The primary application, used in critical contact zones of glass melting furnaces.
- NON-FERROUS INDUSTRY: Linings for copper or other specialty metal melting/refining vessels where high corrosion resistance is mandatory.
- SPECIALTY CHEMICALS: High-temperature reactors involving corrosive fluxes.
- FURNACE AREAS AND SERVICE ZONES
- GLASS TANK BOTTOMS AND SIDEWALLS: Used in the immediate contact zone with the molten glass (metal line) due to its resistance to upward drilling and horizontal wear.
- BURNER PORTS AND THROATS: High-wear, high-temperature zones where erosion from high-velocity gases and melt-flow is severe.
- SLAG LINE: Used where the lining is continuously attacked by the corrosive slag layer floating on the melt.
- KEY DATA SHEET PROPERTIES TO CONSIDER
- APPARENT POROSITY (AP): THE CRITICAL VALUE. Must be reported as near zero (typically <1.0%) to confirm the fusion-cast nature and corrosion resistance.
- BULK DENSITY (BD): Must be extremely high (e.g., 2.9 to 3.1 g/cm3), reflecting the lack of pores.
- EROSION RATE: Look for supplier data showing a dramatically lower erosion rate compared to sintered refractories in glass or slag corrosion tests.
- IMPURITY CONTENT (FE2O3, ALKALIES): Must be minimized to ensure high glass quality and maximum refractoriness.
- TECHNICAL GUIDANCE
- Cast Mullite is a premium, high-cost solution justified only in zones of EXTREME CORROSION and EROSION where campaign life is the primary driver.
- CAUTION: Due to its density, Cast Mullite has POOR THERMAL SHOCK RESISTANCE. Care must be taken during the initial heat-up and any subsequent repairs to ensure slow, controlled temperature changes to prevent cracking. Use specialized, low-shrinkage mortar for joints.
