Crucible – Graphite
Alumina Crucibles are high-purity refractory containers made from sintered aluminum oxide (Al2O3), typically ranging from 95% to 99.8% Al2O3. They are considered the standard for high-purity, high-temperature processing and analysis, valued for their extreme refractoriness, low reactivity, high mechanical strength at heat, and excellent electrical resistance.
Main Chemical Compositions & Categories
Alumina Crucibles are classified by their purity, which directly dictates their maximum service temperature (MST), chemical inertness, and price.
| PURITY GRADE | Al2O3 Content | TYPICAL MST | PRIMARY ADVANTAGE |
| Standard Purity | 95% to 96% | ~1700°C | Good mechanical strength, most cost-effective. |
| High Purity | 99.5% to 99.8% | ~1750°C to 1850°C | Maximum refractoriness and chemical inertness, minimal contamination. |
Key Properties and Performance
| PROPERTY | HIGH PURITY ALUMINA | MECHANISM OF ADVANTAGE |
| Melting Point | ~2050°C | Allows for service temperatures up to ~1850°C. |
| Chemical Inertness | EXCELLENT | Resists attack from many acidic and neutral chemicals, making it ideal for high-purity melts. |
| Hot Strength | HIGH | Maintains structural integrity and load-bearing capacity even at near-peak operating T. |
| Gas Tightness | EXCELLENT | Can be manufactured to be non-porous and vacuum-tight. |
Advantages and Key Characteristics
Alumina crucibles are the preferred choice for processes that demand chemical stability, minimal contamination, and thermal endurance beyond the limits of glass, quartz, or lower-grade ceramics.
- Purity and Contamination Control: The high Al2O3 content ensures that the crucible will not introduce impurities into the sample or melt. This is crucial for electronic materials, specialty glasses, and catalyst research where trace elements can ruin the product.
- High Thermal Endurance: Alumina maintains its crystalline structure and mechanical strength at extremely high temperatures, far exceeding those of most metal alloys, making it suitable for high-temperature sintering, melting, and calcination.
- Dimensional Stability: The high-density sintered structure ensures minimal shrinkage or deformation even after multiple heating cycles, which is important for quantitative analysis and maintaining process control.
- Electrical Insulation: Al2O3 is an excellent electrical insulator, allowing these crucibles to be used safely in electrically heated furnaces, particularly induction and resistance furnaces.
Typical Industries and Applications
This type of crucible is fundamental in both scientific research and industrial high-temperature manufacturing:
- Laboratories & Research: Differential Thermal Analysis (DTA), Thermogravimetric Analysis (TGA), high-temperature material synthesis, and sintering of ceramics/metal powders.
- Metallurgy: Melting and holding noble metals (gold, platinum), high-purity super-alloys, and reactive metals.
- Electronics & Photonics: Growing single crystals, sintering electronic ceramics, and preparing glass preforms for fiber optics.
- Chemical Industry: Calcination and high-temperature chemical reactions involving corrosive media.
Selection and Maintenance
Selection should prioritize the required purity and gas-tightness for the application:
- High Purity (99.8%): Mandatory when working with platinum group metals, electronic materials, or any substance where parts-per-million (ppm) contamination is unacceptable.
- Standard Purity (95%): Suitable for general-purpose ashing, calcining, and melting of non-sensitive materials.
- Porosity: Non-porous, high-density crucibles are required for high-vacuum and liquid-holding applications, while slightly porous crucibles are acceptable for gas-permeable reactions.
Technical Guidance: Alumina crucibles are chemically resistant to acidic and neutral melts. They are, however, attacked by highly basic materials (e.g., CaO, MgO, or basic fluxes) at high temperatures and will also react with pure silicon and iron melts under reducing conditions. They should be handled carefully, as they are brittle and susceptible to cracking from severe thermal shock or physical impact.
