Alumina Lining Plates
Main Chemical Compositions & Categories
Alumina Lining Plates are highly specialized ceramics, distinct from fired refractory bricks. They are classified by ultra-high Al2O3 content, typically sintered at very high temperatures.
| Category | Al2O3 Content | Classification |
| High Purity | 90% to 92% | Standard Wear-Grade |
| Ultra Purity | 95% to 97% | Enhanced Chemical/Wear Resistance |
| Corundum Grade | 99% + | Extreme Purity/Corrosion Resistance |
Key Properties and Performance
| Property | Typical Performance | Variation with Al2O3 Content |
| Temperature Under Load (TUL) | Excellent (typically 1600°C+) | Increases with purity; service is often limited by the adhesive used for installation. |
| Thermal Shock | Good to Very Good | Improves slightly with lower porosity and certain grain structures; generally very reliable. |
| Corrosion | Excellent resistance to acids, alkalis, and moisture | Increases significantly with Al2O3 content/purity, due to reduced glass phase and impurities. |
| Mechanical Strength/Wear | Exceptional Hardness (Mohs 9) | Increases significantly with Al2O3 content and Bulk Density (BD). This is the primary driver for its use. |
Advantages and Key Characteristics
Alumina Lining Plates (often called ceramic tiles or wear plates) are defined by their extreme hardness and density, providing unparalleled protection against abrasion and impact in material handling systems.
- Superior Wear Life: They can offer a lifespan 10 to 20 times longer than steel, significantly reducing maintenance and downtime.
- High Density and Low Porosity: The high sintering temperature results in an extremely dense structure, minimizing material penetration and chemical erosion.
- Lightweight: With a density roughly half that of steel, they reduce the structural load on equipment like chutes and cyclones.
- Chemical Inertness: Provides excellent resistance to corrosive agents, moisture, and fine materials that might chemically attack other linings.
Typical Industries and Applications
These plates are essential in any industry dealing with the high-speed movement and impact of abrasive bulk materials:
- Mining & Aggregate: Chutes, hoppers, feed bins, screens.
- Coal & Power Generation: Coal pulverizer pipes, transport chutes, bunkers, fan blades.
- Ferrous Industry: Sinter plants, coke plants, blast furnace feed systems (trolleys, hoppers).
- Cement & Lime: Crusher housings, cyclones, vertical mill linings, ductwork.
Furnace Areas and Service Zones (Abrasion Focus)
While less common for direct molten metal contact than bricks, they are crucial for asset longevity in material charging/handling:
- Material Transfer Systems: Elbows, bends, pipes, and chutes where high-velocity particles cause impact and sliding abrasion.
- Crushers and Mills: Protection against high kinetic energy impacts from large, hard materials.
- Cyclones and Separators: Linings where turbulent, fast-moving abrasive particles cause severe erosion.
Key Data Sheet Properties to Consider
When selecting Alumina Lining Plates, the focus shifts away from thermal load to mechanical properties:
- Al2O3 Content: Directly correlates with hardness, density, and wear resistance (aim for 90% and above).
- Bulk Density (BD): Crucial. Higher BD ($\sim$3.6 g/cm³+) means lower porosity and superior abrasion resistance.
- Hardness (Mohs/Vickers): The defining property. Look for values confirming Mohs 9, indicating hardness second only to diamond.
- Wear Loss (%): Measured via standard tests (e.g., Taber or ASTM methods); a lower percentage indicates better performance.
- Bonding Method: Determine if the plates are supplied pre-assembled on rubber/steel backing (for impact absorption) or for direct adhesive application.
Technical Guidance: Alumina Lining Plates offer maximum protection against pure abrasion. For systems involving high heat and abrasion, ensure the adhesive (epoxy) or the chosen backing material can handle the maximum service temperature. For severe impact applications, consider ceramic embedded in a rubber or steel composite backing for energy absorption.
