Al₂O₃‑SiC‑C Composite Brick – Runner
Main Chemical Compositions & Categories
The Runner Brick is a dense, high-performance refractory made from a matrix of high-purity ALUMINA (Al2O3), SILICON CARBIDE (SiC), and CARBON (C) (usually graphite). The composite is resin-bonded and unfired (or lightly fired) to maintain carbon content.
| COMPONENT | FUNCTION | ADVANTAGE GAINED |
| ALUMINA (Al2O3) | Structural Strength / Hot Resistance | Provides the backbone and load-bearing capacity. |
| SILICON CARBIDE (SiC) | Thermal Conduction / Abrasion | Increases resistance to thermal shock and physical wear. |
| CARBON (C) | Non-Wetting / Oxidation Resistance | CRITICAL: Prevents molten metal/slag from adhering to the running surface. |
Key Properties and Performance
| PROPERTY | TYPICAL PERFORMANCE | MECHANISM OF ADVANTAGE |
| Non-Wetting | EXCELLENT | CARBON (graphite) has very low surface energy, causing molten steel and slag to bead up and run off easily. |
| Erosion Resistance | VERY GOOD | High hardness of Al2O3 and SiC resists the scouring action of the flowing metal/slag mixture. |
| Thermal Shock | VERY GOOD | Low thermal expansion of the carbon phase and high conductivity of SiC minimize internal stress. |
| Slag Resistance | GOOD (to neutral/acidic) | The carbon component slows chemical attack, offering better life than oxide-only refractories. |
Advantages and Key Characteristics
Al2O3-SiC-C Runner Bricks are essential for maintaining smooth, controlled flow of molten metal, ensuring both operational safety and metal quality.
- Minimizes Buildup and Free Flow: The non-wetting property of the carbon ensures that metal and slag do not “freeze” or adhere to the channel walls, maintaining a consistent runner diameter and flow rate. This is critical for processes like torpedo ladle tapping and transfer.
- Contamination Control: The high purity of the composite minimizes the introduction of unwanted inclusions into the metal stream, which is vital for producing high-grade steel.
- Safety and Integrity: Excellent TUL and thermal shock resistance prevent cracking and catastrophic failure in the runner, which could lead to dangerous metal breakouts.3
- Longevity: Designed to handle the combined high-velocity flow, thermal cycling, and chemical attack common in runner systems, offering extended service campaigns.
Typical Industries and Applications
These runners are used throughout the metallurgical industry where molten metal transfer is continuous or highly critical:
- Ferrous Industry: Main runner systems from the blast furnace to the torpedo ladle; casting floors and transfer troughs for ladles and tundishes.4
- Foundry: Large transfer ladles and pouring spouts for high-volume iron and steel casting.
Furnace Areas and Service Zones
They are specified for all areas conveying high-temperature molten metal/slag:
- Trough/Runner Main Channel: Used as the working lining along the entire path of molten metal flow.
- Taphole Areas: Used near the furnace taphole where heat, velocity, and slag-metal contact are most severe.
- Dam/Weir Sections: Used to build specialized structures within the runner to separate slag from the metal stream.
Key Data Sheet Properties to Consider
Performance is measured by wear resistance and non-wetting characteristics:
- Bulk Density (BD): Must be high (e.g., > 2.8 g/cm3) for maximized erosion resistance.
- Carbon Content: CRITICAL VALUE. Must be high enough (e.g., 5% to 15%) to ensure effective non-wetting properties.
- Oxidation Resistance: Look for suppliers that utilize anti-oxidation additives (e.g., Al or Si) to protect the carbon from burning out in service.
- Apparent Porosity (AP): Should be minimized to prevent penetration.
Technical Guidance: Due to the carbon content, these bricks are susceptible to OXIDATION if exposed to air at high temperatures. They must be installed correctly, minimizing joints, and may require a protective wash coating to maximize life. Specify this product when controlling metal flow, preventing buildup, and minimizing erosion are the primary goals, outperforming high-alumina runners in these critical areas.
